Recessed Shower Niche Frame with Center Shelf — Front Elevation, Top Plan View, Right Elevation

Free Recessed Shower Niche Frame with Center Shelf DWG — Plan and Elevation

This free recessed shower niche frame with center shelf dwg includes front elevation, top plan view, right elevation of one object. The free recessed shower niche frame with center shelf dwg uses millimetres at 1:1 model scale and organized drawing layers. No sign-up or payment required.

What’s Inside This DWG?

100% Free: No sign-up, no payment. Download after a short timer.
Views Included: Front Elevation, Top Plan View, Right Elevation
Pro Standards: Drawn to real-world architectural proportions.
Ready to Use: Open-front rectangular recessed shower niche box with back panel and one internal shelf.

Technical Specifications:

Detail	Info
File Format	.DWG — AutoCAD 2010+, AutoCAD LT, BricsCAD
Measurement System	Metric (millimetres)
Scale	1:1 (real-world units)
Layer	Organized Layers
Category	Bathroom Fixtures

Ready to download Free Recessed Shower Niche Frame with Center Shelf DWG Download

Save to Pinterest

Frequently Asked Questions

Q: Which programs can open this DWG?

A: AutoCAD 2010 or newer, AutoCAD LT and BricsCAD support this file format.

Q: What are the drawing dimensions?

A: The annotated front-view width is 600 mm and height is 400 mm. The design depth is 120 mm.

Q: Is this a fabrication drawing?

A: No. This is a schematic architectural block, not an engineering or fabrication specification.

Q: How can I download the file?

A: Use the download button on this page. The download starts after the short timer; no account or payment is required.

Q: Where can I find more free DWG files?

A: Browse the OpenCADFiles categories for more architectural drawing blocks.

For more drawing options, explore the OpenCADFiles premium collection.
