FREE BATHTUB LONGITUDINAL SECTION DWG — INNER BASIN SLOPES AND SUPPORT LEGS

This free bathtub longitudinal section dwg provides five distinct cut-away profiles for detailing your interior plumbing sheets. The 2D CAD drawing explicitly reveals the sloped interior basins resting on adjustable support legs, alongside hatched structural walls on the right side of each unit. Inserting this free bathtub longitudinal section dwg into your wet room elevations allows you to accurately align the tub aprons and calculate under-floor clearance for drainage pipes. No sign-up or payment required.

What’s Inside This DWG?

• 100% Free: No sign-up, no payment. Download instantly.
• Views Included: Section View, Front Elevation
• Pro Standards: Drawn to real-world architectural proportions.
• Ready to Use: The file includes pre-drawn hatched wall abutments on the right side of each tub section, helping you immediately anchor the fixtures to your bathroom partitions.

Technical Specifications:

Detail	Info
File Format	.DWG — AutoCAD 2010+, LT, BricsCAD, LibreCAD
Measurement System	Metric
Scale	1:1 (real-world units)
Layer	Organized Layers
Category	Kitchen and Bathroom

Frequently Asked Questions

Q: Which AutoCAD versions and alternative programs open this file?

A: You can open this DWG file using AutoCAD 2010 or newer, AutoCAD LT, BricsCAD, LibreCAD, or any other standard CAD drafting program.

Q: What are the real-world dimensions of the bathtub sections shown?

A: The cross-sections represent standard metric tub lengths ranging roughly from 1500mm to 1800mm, with typical apron heights around 500mm to 600mm. Everything is drafted exactly at a 1:1 scale.

Q: How do I download this file for free?

A: Simply click the download button labeled

on this page to get the file instantly. You do not need to create an account or provide payment details.

Q: Does the drawing show the mounting hardware or floor supports beneath the tub?

A: Yes, the section views clearly detail the adjustable support legs positioned under the molded basins, which are crucial for establishing the finished floor height before tiling.
